This post walks you through the step-by-step process of flashing MicroPython firmware onto the ESP32-C5_MINI . 1. Download the MicroPython Firmware First, grab the correct binary for your chip: Visit the official MicroPython Download Page . Search or scroll down to the ESP32 section and locate the ESP32-C5 targets. Select ESP32-C5 by Espressif and download your preferred .bin file version. 2. Flash the Firmware (The 0x2000 Offset) To flash the firmware, connect your board to your computer and run the following esptool command. ⚠️ Crucial Note: Unlike older ESP32 chips (like the S3) which often start flashing at 0x0 , the ESP32-C5 requires you to write the flash starting exactly at address 0x2000 . Run this command in your terminal (replace PORTNAME and the .bin filename with your actual values): esptool --port PORTNAME ...

Hello World on ESP32-C5_MIINI , list info and blink onboard LED (on IO23). ESP32-C5_MINI_hello.ino #define LED 23 void setup() { delay(2000); Serial.begin(115200); delay(1000); // initialize digital pin of the ESP32-C5_MINI onboard LED as an output. pinMode(LED, OUTPUT); digitalWrite(LED, LOW); // LED ON Serial.println("\n===================================="); Serial.println("Arduino_Hello World example"); Serial.println("ESP32-C5_MINI"); Serial.println("===================================="); Serial.printf("Chip model: %s\n", ESP.getChipModel()); Serial.printf("Chip revision: %d\n", ESP.getChipRevision());// Get ESP-IDF Version Serial.print("ESP-IDF Version: "); Serial.println(esp_get_idf_version()); #ifdef ESP_ARDUINO_VERSION_STR Serial.print("Arduino-ESP32 Core Version (String): "); Serial.println(ESP_ARDUINO_VERSION_STR); #else Serial.println("E...

ESP32-C5_MINI esptool read flash-id of ESP32-C5_MINI esptool --port COM4 flash-id Exercises: ~ Hello ESP32-C5_MIINI MicroPython: ~  Flashing MicroPython Firmware on the ESP32-C5_MINI using esptool ~  Drive an SSD1315 I2C OLED Display on ESP32-C5_MINI with MicroPython

my dev.board WeActStudio.STM32G474CoreBoard Github: https://github.com/WeActStudio/WeActStudio.STM32G474CoreBoard.git Gitee: https://gitee.com/WeAct-TC/WeActStudio.STM32G474CoreBoard.git

Basic Test run on  Waveshare ESP32-S3-Touch-LCD-4B , with built-in 4inch 480 × 480 resolution ST7701 RGB interface LCD. S3_ST7701_basictest.ino /* Basic test run on Waveshare ESP32-S3-Touch-LCD-4B https://coxxect.blogspot.com/2026/06/waveshare-esp32-s3-touch-lcd-4b-hello.html Remark about "USB CDC On Boot" option for Serial.print() If host PC connect to USB TO UART port (lower one), select USB CDC On Boot: "Disabled". If connect to ESP32-S3 USB Interface port (middle one), select USB CDC On Boot: "Enabled" Otherwise, you cannot see the output by Serial.print(). */ #include <Arduino.h> #include "Arduino_GFX_Library.h" #define BL 4 Arduino_XCA9554SWSPI *expander = new Arduino_XCA9554SWSPI( 7, 0, 2, 1, &Wire, 0x20); Arduino_ESP32RGBPanel *rgbpanel = new Arduino_ESP32RGBPanel( 17 /* DE */, 3 /* VSYNC */, 46 /* HSYNC */, 9 /* PCLK */, 10 /* B0 */, 11 /* B1 */, 12 /* B2 */, 13 /* B3 */, 14 /* B4 */, 21 ...

In my previous post, I demonstrated how to download and display JPG images via WiFi on the Waveshare ESP32-C5-WIFI6-KIT-N16R8 with an 240x320 ST7789 SPI TFT LCD using hardcoded filenames . This new implementation is much more flexible: filenames are now stored in a jpg_list.txt file on the server, allowing the ESP32 to download the images dynamically. I have also successfully tested this setup on the Waveshare ESP32-S3-Touch-AMOLED-2.16 with its 480x480 AMOLED (CO5300 driver) . (Scroll down for ESP32-S3-Touch-LCD-4B version). How it Works The program operates in three distinct phases: WiFi connection: The ESP32-S3 connects to a local WiFi access point and establishes communication with a Python-based HTTP server. Since the WiFi access point is a Windows 11 Mobile Hotspot and the Python-based HTTP server is running on that same PC, we can assume the server IP address is identical to the Access Point (Gateway) IP. Dynamic Manifes...
